Application
State the operating area, access frequency and any wet, corrosive or public-safety conditions.
Manufactured component
Anchor Bolts & Anchors
Anchor bolts for grating support frames, guardrail posts, trench cover frames and equipment bases. Supplied with coordinated packages or as separate items.
Material & finish optionsCarbon steel / SS400 — HDGStainless steel — 304 / 316LOther materials on request
Configured for industrial projects
Built around your operating conditions.
Anchor bolts for grating support frames, guardrail posts, trench cover frames and equipment bases. Supplied with coordinated packages or as separate items.
- Dimensions, material and finish confirmed against drawings
- Engineering support for spans, loads, installation and standards
- Coordinated supply with frames, fixings and edge protection
What we supply
- Cast-in anchors — J-bolts (90° hook) and L-bolts. M12–M36. ASTM F1554 Gr.36 standard; Gr.55 medium-strength
- Post-installed anchors — wedge anchors and chemical/epoxy anchors for existing concrete. M10–M30
- Plate-welded anchor assemblies — bolt welded to steel base plate. M16–M64 for heavy structural connections
- High-strength bolts: ISO 898-1 Grade 8.8 and Grade 10.9. Hot-dip galvanized to ASTM A153
- Stainless steel 304/316L bolts, nuts and washers for marine, offshore and chemical environments
- Matching nuts, flat washers and spring washers supplied per bolt. Quantities confirmed on quotation
Used in
Industries
How to order
- Bolt type: J-bolt / L-bolt / wedge anchor / chemical anchor / plate-welded
- Diameter and length — or send the equipment base / frame drawing
- Material and grade: ASTM F1554 Gr.36 / Gr.55 / Grade 8.8 / 316L
- Quantity per size and delivery destination
Supplied to your drawings and project standard. Load tables → · Downloads →
Selection support
What to confirm before quotation.
Share the application, load, span, material and finish with the RFQ.
Engineering inputs
Provide clear span, bearing direction, design load, dimensions and required standards.
Supply scope
Include frames, clips, banding, toe plates, railings and drawings in one coordinated RFQ.
Typical systems
Discuss the operating environment with our engineering team.
Typical industries
Discuss the operating environment with our engineering team.
