Manufactured component
Stair Connections
Connection components for industrial stair systems — tread brackets, stringer plates, handrail flanges and landing connectors. Fabricated to your drawings.
Material & finish optionsCarbon steel / SS400 — HDGStainless steel — 304 / 316LOther materials on request
Configured for industrial projects
Built around your operating conditions.
Connection components for industrial stair systems — tread brackets, stringer plates, handrail flanges and landing connectors. Fabricated to your drawings.
- Dimensions, material and finish confirmed against drawings
- Engineering support for spans, loads, installation and standards
- Coordinated supply with frames, fixings and edge protection
What we supply
- Tread-to-stringer brackets — angle steel 50 × 50 × 6 mm, S275JR / ASTM A36, with pre-drilled bolt holes
- Handrail post base plates — 150 × 150 × 10 mm with 4 × M12 bolt holes. Welded to post bottoms
- Stringer-to-landing gusset plates — 10–16 mm plate thickness. Connection bolts M16–M20
- Bolts: M12–M20, ISO 898-1 Grade 8.8 hot-dip galvanized. Grade 10.9 for heavy-duty
- Stainless steel 316L bolts and plates for marine, offshore and chemical environments
- All components hot-dip galvanized to ASTM A123 / EN ISO 1461 unless specified otherwise
- Quantities, dimensions and bolt grades confirmed on the quotation against your drawings
Used in
How to order
- Stair configuration and stringer details
- Connection type and bolt grade preference
- Material preference: carbon steel HDG / 316L
- Quantity and delivery destination
Supplied to your drawings and project standard. Load tables → · Downloads →
Selection support
What to confirm before quotation.
Share the application, load, span, material and finish with the RFQ.
Engineering inputs
Provide clear span, bearing direction, design load, dimensions and required standards.
Supply scope
Include frames, clips, banding, toe plates, railings and drawings in one coordinated RFQ.
Typical systems
Discuss the operating environment with our engineering team.
Typical industries
Discuss the operating environment with our engineering team.
