Manufactured component
Stair Landings
Intermediate platform landings for industrial stair systems. Fabricated to your stair width and project code—supplied with treads, handrails and connections as one package.
Material & finish optionsCarbon steel / SS400 — HDGStainless steel — 304 / 316LOther materials on request
Configured for industrial projects
Built around your operating conditions.
Intermediate platform landings for industrial stair systems. Fabricated to your stair width and project code—supplied with treads, handrails and connections as one package.
- Dimensions, material and finish confirmed against drawings
- Engineering support for spans, loads, installation and standards
- Coordinated supply with frames, fixings and edge protection
What we supply
- Angle steel frame — S275JR / ASTM A36 / SS400. Hot-dip galvanized to ASTM A123 / EN ISO 1461
- Grating infill panel — serrated welded bar grating for outdoor and wet areas. Plain or close-mesh for indoor
- Typical depths: 750 mm (AS 1657), 762 mm / 30 in (OSHA 1910.25), 1000–1200 mm for wider stairs
- Landing width matches stair width. Standard widths 800, 900, 1000, 1200 mm
- Edge banding and toe plates (100 mm high) included where required by the project code
- Stainless steel 304/316L for corrosive, marine and food-grade environments
- Connection points for stair stringers, handrail posts and adjacent landings prepared per drawing
Used in
How to order
- Stair width and landing depth
- Number of landings and positions (intermediate / top / bottom)
- Material preference: carbon steel HDG / 304 / 316L
- Toe plate and handrail connection requirements
Supplied to your drawings and project standard. Load tables → · Downloads →
Selection support
What to confirm before quotation.
Share the application, load, span, material and finish with the RFQ.
Engineering inputs
Provide clear span, bearing direction, design load, dimensions and required standards.
Supply scope
Include frames, clips, banding, toe plates, railings and drawings in one coordinated RFQ.
