Application
State the operating area, access frequency and any wet, corrosive or public-safety conditions.
Manufactured component
Safety Gates
Self-closing swing gates for platform openings, ladder tops and stair access points. Supplied as part of edge-protection packages.
Configured for industrial projects
Built around your operating conditions.
Self-closing swing gates for platform openings, ladder tops and stair access points. Supplied as part of edge-protection packages.
- Dimensions, material and finish confirmed against drawings
- Engineering support for spans, loads, installation and standards
- Coordinated supply with frames, fixings and edge protection
At a glance
- Single or double leaf, self-closing spring hinge
- Clear opening 500–1200 mm, matching platform gap
- Height 1050 or 1100 mm to match guardrail
- Frame tube Ø33.7–42.4 mm. Q235B HDG or 304 / 316L
- Magnetic catch or gravity latch — no-hands closure
- Integrated 100 mm toe plate on bottom rail
Specifications
| Parameter | Standard range |
|---|---|
| Type | Self-closing swing gate, single or double leaf |
| Width | 500–1200 mm clear opening |
| Height | 1050 mm or 1100 mm (match guardrail) |
| Frame | Ø33.7–42.4 mm tube, Q235B HDG / 304 / 316L |
| Closure | Spring-loaded hinge. Opens per drawing direction |
| Latch | Magnetic catch or gravity latch |
| Toe plate | Integrated 100 mm on bottom rail |
Supplied with
Selection support
What to confirm before quotation.
Share the application, load, span, material and finish with the RFQ.
Engineering inputs
Provide clear span, bearing direction, design load, dimensions and required standards.
Supply scope
Include frames, clips, banding, toe plates, railings and drawings in one coordinated RFQ.
Typical systems
Discuss the operating environment with our engineering team.
Typical industries
Discuss the operating environment with our engineering team.
Send opening width, height and guardrail match.
Coordinated supply with edge-protection packages.
