Manufactured component
Support Frames & Edge Bands
Structural steel frames, edge banding and toe plates fabricated to project drawings for grating support.
Configured for industrial projects
Built around your operating conditions.
Structural steel frames, edge banding and toe plates fabricated to project drawings for grating support.
- Dimensions, material and finish confirmed against drawings
- Engineering support for spans, loads, installation and standards
- Coordinated supply with frames, fixings and edge protection
At a glance
- Angle steel (L-type), channel steel (C-type), I-beam — Q235B / SS400
- Edge banding flat bar 40–100 mm deep × 4–10 mm thick
- Toe plate 100 mm × 4 mm. Welded or bolted to frames
- Bolted splice plates, welded gussets, pre-drilled mounting holes
- HDG ≥85µm standard. Stainless 304 / 316L for corrosive environments
Specifications
| Parameter | Standard range |
|---|---|
| Frame types | L-angle, C-channel, I-beam — Q235B / SS400 |
| Edge banding | Flat bar 40–100 mm deep × 4–10 mm thick |
| Toe plate | 100 mm × 4 mm. Welded or bolted to frames |
| Surface | HDG ≥85µm · 304 · 316L · painted (RAL) |
| Connections | Bolted splice plates, welded gussets, pre-drilled |
Supplied with
Selection support
What to confirm before quotation.
Angle or channel frames. Edge bands close grating panel ends for strength and safety.
Engineering inputs
Provide clear span, bearing direction, design load, dimensions and required standards.
Supply scope
Include frames, clips, banding, toe plates, railings and drawings in one coordinated RFQ.
Typical systems
Typical industries
Send drawing with frame layout and dimensions.
Fabricated to project drawings by the manufacturer.
